Transistors - Bipolar (BJT) - Arrays, Pre-Biased- Page 3

MAX3232IDR BT1433 5-160558-2 ESD9B5.0ST5G

Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	TransistorType	Current-Collector(Ic)(Max)	Voltage-CollectorEmitterBreakdown(Max)	Resistor-Base(R1)	Resistor-EmitterBase(R2)	DCCurrentGain(hFE)(Min)@IcVce	VceSaturation(Max)@IbIc	Current-CollectorCutoff(Max)	Frequency-Transition	Power-Max	MountingType
PBLS6004D,115 TRANS PREBIAS 1NPN 1PNP 6TSOP Nexperia USA Inc.	319	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	1 NPN Pre-Biased, 1 PNP	100mA, 700mA	50V, 60V	22kOhms	22kOhms	60 @ 5mA, 5V / 150 @ 500mA, 5V	150mV @ 500µA, 10mA / 340mV @ 100mA, 1A	1µA, 100nA	185MHz	600mW	Surface Mount
PBLS2004D,115 TRANS PREBIAS 1NPN 1PNP 6TSOP Nexperia USA Inc.	2,169	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	1 NPN Pre-Biased, 1 PNP	100mA, 1A	50V, 20V	22kOhms	22kOhms	60 @ 5mA, 5V / 220 @ 500mA, 2V	150mV @ 500µA, 10mA / 280mV @ 100mA, 1A	1µA, 100nA	185MHz	600mW	Surface Mount
PBLS4003D,115 TRANS PREBIAS 1NPN 1PNP 6TSOP Nexperia USA Inc.	2,173	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	1 NPN Pre-Biased, 1 PNP	100mA, 700mA	50V, 40V	10kOhms	10kOhms	30 @ 5mA, 5V / 300 @ 100mA, 5V	150mV @ 500µA, 10mA / 310mV @ 100mA, 1A	1µA, 100nA	150MHz	600mW	Surface Mount
EMB51T2R TRANS 2PNP PREBIAS 0.15W EMT6 Rohm Semiconductor	2,356	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 PNP - Pre-Biased (Dual)	30mA	50V	22kOhms	22kOhms	60 @ 5mA, 10V	150mV @ 500µA, 5mA	500nA	250MHz	150mW	Surface Mount
RN2713JE(TE85L,F) TRANS 2PNP PREBIAS 0.1W ESV Toshiba Semiconductor and Storage	3,262	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 PNP - Pre-Biased (Dual) (Emitter Coupled)	100mA	50V	47kOhms	-	120 @ 1mA, 5V	300mV @ 250µA, 5mA	100nA (ICBO)	200MHz	100mW	Surface Mount
RN2711JE(TE85L,F) TRANS 2PNP PREBIAS 0.1W ESV Toshiba Semiconductor and Storage	3,244	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 PNP - Pre-Biased (Dual) (Emitter Coupled)	100mA	50V	10kOhms	-	120 @ 1mA, 5V	300mV @ 250µA, 5mA	100nA (ICBO)	200MHz	100mW	Surface Mount
UMF5NTR TRANS NPN PREBIAS/PNP 0.15W UMT6 Rohm Semiconductor	2,433	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	1 NPN Pre-Biased, 1 PNP	100mA, 500mA	50V, 12V	47kOhms	47kOhms	68 @ 5mA, 5V / 270 @ 10mA, 2V	300mV @ 500µA, 10mA / 250mV @ 10mA, 200mA	500nA	250MHz, 260MHz	150mW	Surface Mount
EMD62T2R TRANS NPN/PNP PREBIAS 0.15W EMT6 Rohm Semiconductor	2,434	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	47kOhms	47kOhms	80 @ 5mA, 10V	150mV @ 500µA, 5mA	500nA	250MHz	150mW	Surface Mount
DMA566050R TRANS PREBIAS DUAL PNP SMINI6 Panasonic Electronic Components	2,869	-	RFQ		Tape & Reel (TR),Cut Tape (CT)	-	Obsolete	2 PNP - Pre-Biased (Dual)	100mA	50V	10kOhms	-	160 @ 5mA, 10V	250mV @ 500µA, 10mA	500nA	-	150mW	Surface Mount
RN4610(TE85L,F) TRANS NPN/PNP PREBIAS 0.3W SM6 Toshiba Semiconductor and Storage	3,043	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	4.7kOhms	-	120 @ 1mA, 5V	300mV @ 250µA, 5mA	100nA (ICBO)	200MHz	300mW	Surface Mount
UMG2NTR TRANS 2NPN PREBIAS 0.15W UMT5 Rohm Semiconductor	2,609	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT),Cut Tape (CT)	-	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	47kOhms	47kOhms	68 @ 5mA, 5V	300mV @ 500µA, 10mA	500nA	250MHz	150mW	Surface Mount
RN1611(TE85L,F) TRANS 2NPN PREBIAS 0.3W SM6 Toshiba Semiconductor and Storage	3,916	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	10kOhms	-	120 @ 1mA, 5V	300mV @ 250µA, 5mA	100nA (ICBO)	250MHz	300mW	Surface Mount
FMA2AT148 TRANS PREBIAS DUAL PNP SMT5 Rohm Semiconductor	3,754	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 PNP - Pre-Biased (Dual)	100mA	50V	47kOhms	47kOhms	68 @ 5mA, 5V	300mV @ 500µA, 10mA	500nA	250MHz	300mW	Surface Mount
IMH5AT108 TRANS PREBIAS DUAL NPN SMT6 Rohm Semiconductor	3,020	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	22kOhms	22kOhms	56 @ 5mA, 5V	300mV @ 500µA, 10mA	500nA	250MHz	300mW	Surface Mount
RN1702JE(TE85L,F) TRANS 2NPN PREBIAS 0.1W ESV Toshiba Semiconductor and Storage	3,838	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 NPN - Pre-Biased (Dual) (Emitter Coupled)	100mA	50V	10kOhms	10kOhms	50 @ 10mA, 5V	300mV @ 250µA, 5mA	100nA (ICBO)	250MHz	100mW	Surface Mount
RN1705JE(TE85L,F) TRANS 2NPN PREBIAS 0.1W ESV Toshiba Semiconductor and Storage	2,131	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 NPN - Pre-Biased (Dual) (Emitter Coupled)	100mA	50V	2.2kOhms	47kOhms	80 @ 10mA, 5V	300mV @ 250µA, 5mA	100nA (ICBO)	250MHz	100mW	Surface Mount
RN2704JE(TE85L,F) TRANS 2PNP PREBIAS 0.1W ESV Toshiba Semiconductor and Storage	3,139	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 PNP - Pre-Biased (Dual) (Emitter Coupled)	100mA	50V	47kOhms	47kOhms	80 @ 10mA, 5V	300mV @ 250µA, 5mA	100nA (ICBO)	200MHz	100mW	Surface Mount
RN2701JE(TE85L,F) TRANS 2PNP PREBIAS 0.1W ESV Toshiba Semiconductor and Storage	3,305	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 PNP - Pre-Biased (Dual) (Emitter Coupled)	100mA	50V	4.7kOhms	4.7kOhms	30 @ 10mA, 5V	300mV @ 250µA, 5mA	100nA (ICBO)	200MHz	100mW	Surface Mount
RN2710JE(TE85L,F) TRANS 2PNP PREBIAS 0.1W ESV Toshiba Semiconductor and Storage	3,106	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 PNP - Pre-Biased (Dual) (Emitter Coupled)	100mA	50V	4.7kOhms	-	120 @ 1mA, 5V	300mV @ 250µA, 5mA	100nA (ICBO)	200MHz	100mW	Surface Mount
RN2965(TE85L,F) TRANS 2PNP PREBIAS 0.2W US6 Toshiba Semiconductor and Storage	3,616	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2 PNP - Pre-Biased (Dual)	100mA	50V	2.2kOhms	47kOhms	80 @ 10mA, 5V	300mV @ 250µA, 5mA	100nA (ICBO)	200MHz	200mW	Surface Mount
